SD012 Service & Boot Door
Type:
SD012
Category:
Application:
Caravan trailer and motorhome
Features:
Light , simple ,reliable, cheap.
隐藏域元素占位
Feature & Main Functions
|
Frame & Panel |
Powder coated high quality aluminum alloy. |
|
Color |
White, black, or customizable. |
|
Opening Angle |
0-180 ° . |
|
Install |
Can be installed on all wall thicknesses. External fixing by screw. |
Type Description
|
SD012 |
Epresents product code. |
|
H x W |
Height / Width of door size, unit: mm |
|
T/B/L/R |
Stands for the position of the hinges at Top / Bottom / Left / Right. |
|
WH/BL |
White / Black color. |
Example：SD012-200x455-T-BL
Stands for the size of service door fitting surface 200x455mm, hinges at top, black color.
Specifications
|
Type /mm SD010-H x W |
Overall (H+34) x (W+34) |
Cut hole（MAX） (H+3)x(W+3) |
|
SD012-200x455 |
248x503 |
208x463 |
|
SD012-300x455 |
348x503 |
308x463 |
|
SD012-300x610 |
348x658 |
308x618 |
|
SD012-260x725 |
308x773 |
268x733 |
Regular sizes: Short delivery cycle, lower prices.
Other sizes can be customized after discussing.
