MD3 Motorhome/Caravan Door
Type:
MD3
Category:
Application:
Self-propelled RV/Trailer RV
Features:
Has good sound insulation, heat insulation and waterproof properties. The entire door is installed from outside the wall. It is suitable for a wide range of wall thicknesses. The internal decorative frame covers the opening and is beautiful.
隐藏域元素占位
Features & Main Functions
The door has good sound insulation, heat insulation and waterproof performance. No need to open the door, the whole door can is installed from outer, suitable for a wide range of wall thickness, and the internal decorative frame covers the opening, which is beautiful. Easy to install, durable.
|
Color |
The regular color is white, or it can be customized according to customer requirements. |
|
Frame & Panel |
high-strength aluminum alloy profile, powder coated. |
|
Windows |
EV or WS25F. |
|
Curtain |
Optional EVBF1 and EVBF1 |
|
Door lock |
single-point American mechanical lock, optional electronic lock. |
| parameters | instruction |
| MD3 | Product model |
| H x W | Indicates the height x width of the product mounting surface |
| EV WS25F |
EV Window WS25F Sliding Window |
| H1 x W1 | height x width of window |
| 2TR 4TR 2TS |
2 Top Round corners door 4 Top Round corners door Square corners door |
| LH RH |
Left hinge door Right hinge door |
Specifications
Overall (H1 x W1) = (H+40) x (W+40)
Cut hole (H2 x W2) = (H+3) x (W+3)
|
Type H x W |
Overall H1 x W1 |
Cut hole(MAX) H2 x W2 |
Weight |
|
mm |
mm |
Kg |
|
|
MD3-915x660 |
955x700 |
918x663 |
15.0 |
Note：Special sizes can be customized after discussing.
